Fun and Games with Overlay Tunnels: Part 1, Dynamic Edge2Edge



 Last week a VMware instructor collegue sent me an interesting question which came up during an SD-WAN course:

 "If I set up  Profile A using Gateways, and Profile B using Hubs, would we set up a dynamic VPN from Edge A with Profile A and Edge B with Profile B?"

My first idea was, that such configuration cannot work, but then I decided to try it in my lab first, before answering that question with a categoric NO.


So I defined 3 different Branch Profiles:


BR-3 is using Gateway for E2E (with no Branch to Hub connectivity)


whereas BR-7 is using the DC-HUB for E2E


When starting communication from BR-7  we see, that no Dynamic E2E tunnel is established:

VPCS> ping 10.1.103.75

84 bytes from 10.1.103.75 icmp_seq=1 ttl=61 time=49.366 ms
84 bytes from 10.1.103.75 icmp_seq=2 ttl=61 time=16.159 ms
84 bytes from 10.1.103.75 icmp_seq=3 ttl=61 time=23.028 ms
84 bytes from 10.1.103.75 icmp_seq=4 ttl=61 time=20.930 ms
84 bytes from 10.1.103.75 icmp_seq=5 ttl=61 time=19.896 ms

VPCS> trace 10.1.103.75
trace to 10.1.103.75, 8 hops max, press Ctrl+C to stop
 1   10.1.107.1   8.755 ms  0.699 ms  1.030 ms
 2   10.10.12.3   69.626 ms  8.462 ms  4.910 ms        < ...DC-Hub
 3   110.1.1.174   19.512 ms  24.615 ms  19.443 ms     < ...Gateway
 4   110.1.1.17   29.702 ms  15.487 ms  7.885 ms       < ...BR-7 WAN IP
 5   *10.1.103.75   51.142 ms (ICMP type:3, code:3, Destination port unreachable)



This is what we would expect in that configuration


But when I reverse the initial communication message and started it from BR-3

As expected, the first packets are forwarded via Gateway:

 VPCS> trace 10.1.107.95
trace to 10.1.107.95, 8 hops max, press Ctrl+C to stop
 1   10.1.103.1   2.847 ms  0.585 ms  1.769 ms
 2   110.1.1.174   25.652 ms  1.800 ms  2.354 ms      <... Gateway
 3   110.1.1.33   14.600 ms  8.164 ms  5.189 ms
 4   *10.1.107.95   36.023 ms (ICMP type:3, code:3, Destination port unreachable)

VPCS> ping 10.1.107.95

84 bytes from 10.1.107.95 icmp_seq=1 ttl=61 time=19.774 ms
84 bytes from 10.1.107.95 icmp_seq=2 ttl=61 time=27.347 ms
84 bytes from 10.1.107.95 icmp_seq=3 ttl=61 time=19.014 ms
84 bytes from 10.1.107.95 icmp_seq=4 ttl=62 time=5.505 ms
84 bytes from 10.1.107.95 icmp_seq=5 ttl=62 time=11.103 ms

But then the TTL jumps from 61 to 62, one hop less, as against my initial assumption a dynamic tunnel has been sucessfully established


VPCS> trace 10.1.107.95
trace to 10.1.107.95, 8 hops max, press Ctrl+C to stop
 1   10.1.103.1   6.424 ms  0.895 ms  0.568 ms
 2   110.1.1.33   43.315 ms  3.747 ms  3.524 ms         <... BR-3 WAN IP
 3   *10.1.107.95   28.896 ms (ICMP type:3, code:3, Destination port unreachable)

and the dynamic tunnel can also be seen using diagnostics

That established tunnel is then used in both directions (also from BR-7 to BR-3)

VPCS> trace 10.1.103.75
trace to 10.1.103.75, 8 hops max, press Ctrl+C to stop
 1   10.1.107.1   5.354 ms  0.548 ms  0.350 ms
 2   110.1.1.17   26.379 ms  2.289 ms  2.479 ms
 3   *10.1.103.75   32.386 ms (ICMP type:3, code:3, Destination port unreachable)

I retested the same situation but changed profile for BR-3 using gateway for E2E and with a permanent tunnel to the DC-HUB as I wanted to see if the result is different, but again only BR-3 could establish a dynamic tunnel and not with initiating packets comming from BR-7.

NOTE: this configuration is neither supported nor recommended but it nicely shows that the VMware SD-WAN overlay trys to establish communication even in seemingly impossible configurations.

As a kind of resume, it seems that whenever there is a static overlay tunnel established from a Branch Edge to a Gateway defined for dynamic E2E traffic, a dynamic E2E tunnel can be established.

On the other hand established overlay tunnels between edges via Hub alone does not alone qualify for establishing a direct dynamic E2E tunnel.
